Vishay / BC Components 152 CME SMD High Voltage Aluminum Capacitors
Vishay / BC Components 152 CME SMD (Chip) High Voltage Aluminum Capacitors offer low ESR, low impedance, and high ripple current. The series features a 400V to 450V rated voltage range and a 2.2µF to 33µF rated capacitance range. The high-reliability capacitors also feature ±20% tolerance and are available in a vibration-proof, 4-pin version as well as a 6-pin version. Vishay / BC Components 152 CME capacitors are AEC-Q200 qualified and are ideal for use in industrial and professional, automotive, and telecom applications.
Features
- Extended useful life: up to 6000h at 105°C
- Polarized aluminum electrolytic capacitors, non-solid electrolyte, self-healing
- SMD-version with base plate, lead (Pb)-free reflow solderable
- Charge and discharge proof, no peak current limitation
- Advanced temperature reflow soldering according to JEDEC® J-STD-020
- Vibration-proof, 4-pin version and 6-pin version
- AEC-Q200 qualified
- High reliability
Applications
- SMD technology, for high temperature reflow soldering
- Industrial and professional applications
- Automotive, general industrial, telecom
- Smoothing, filtering, buffering
Specifications
- 2.2μF to 33μF rated capacitance range
- ±20% tolerance
- 400V to 450V rated voltage range
- -40°C to +105°C temperature operating range
