Bourns SRF1206A AEC-Q200 High Current Common Mode Chokes provide 700Ω and 1000Ω typical common mode (CM) impedance at 100MHz to suppress electromagnetic interference (EMI). These compact chokes measure 12mm x 11mm x 6mm. They offer 9μH and 12.5μH inductance as well as 6A and 8A current ratings. The series features a sector-wound configuration winding for normal common mode impedance and increased differential mode impedance at high frequencies. These chokes offer common mode filtering and differential mode filtering in a single choke configuration. Bourns SRF1206A AEC-Q200 High Current Common Mode Chokes are ideally suited for use in DC/DC converters, switch-mode power supplies, and power line noise suppression and noise filtering.
Shielded construction, low radiation
RoHS compliant and halogen free
EMI suppression and noise filtering in power lines
Switch-mode power supplies
9μH and 12.5μH inductance
700Ω and 1000Ω @ 100MHz typical CM impedance
6A and 8A current
12mm x 11mm x 6mm dimensions
