Analog Devices Inc. ADP1764-EVALZ/ADP1764-ADJ-EVALZ Eval Boards
Analog Devices Inc. ADP1764-EVALZ/ADP1764-ADJ-EVALZ Evaluation Boards demonstrate the functionality of the ADP1764 Low VIN, Low Noise, CMOS Linear Regulators. ADP1764-EVALZ is a fixed output voltage evaluation board and ADP1764-ADJ-EVALZ is an adjustable output voltage evaluation board. Using a single voltage supply, a voltmeter, an ammeter, and load resistors, the ADP1764-EVALZ/ADP1764-ADJ-EVALZ Analog Devices provides simple device measurements such as line and load regulation, dropout voltage, and ground current.
Features
- Full featured evaluation boards for ADP1764
- 1.10V to 1.98V input voltage
- 0mA to 4A output current range
- Evaluation available on an adjustable or fixed output voltage
- Convenient test points for electrical measurements
- -40°C to +125°C operating temperature range
Associated Product
Analog Devices Inc. ADP1764 Low Noise, CMOS Linear Regulators
4A, low VIN, low noise, LDO CMOS linear regulators operate with input voltages as low as 1.10V.
Analog Devices Inc. ADP176x CMOS Linear Regulators
Optimized for stable operation with small 10μF ceramic output capacitors.
